Pro Shot Alpha-c Cone Laser Level (4% Cone Angle) with R9 Detector
SKU: 020-0020-C-4
- The Pro Shot Alpha-c offers the performance of the standard Alpha, plus a custom precision cone rotor head. This version of the Alpha-c offers ±4% cone angle.
The Alpha C can also be used as a conventional laser level when the cone rotor is replaced with the standard rotor cap. The ProShot Laser levels are precision instruments that provide speed, accuracy on the job-site.
The Pro Shot Construction Alpha C lasers combine the most desirable features, durability, accuracy and at the best price in the market. Incorporated in 1991, Laser Reference has sold over 90,000 laser transmitters worldwide. Free UPS USA Shipping!
-
Description
- The Pro Shot Alpha-c offers the performance of the standard Alpha, plus a custom precision cone rotor head. This version of the Alpha-c offers ±4% cone angle.
-
- Pro Shot Alpha-c cone laser 4% (percent) degree plus or minus cone.
- The Alpha C Cone Laser has replaced the L6C cone laser.
- The standard cone rotor provides ±4% cone angle, (#020-0020-C-4) and there is an optional high resolution rotor that provides ±1.7 % (#020-0020-C-1.7).
- The Alpha-c will function as a conventional laser level if the cone rotor is replaced with the included conventional rotor cap.
- The prime uses of the Alpha-c are baseball fields, the curved portion of running tracks, and containment areas around storage tanks.
- Single and dual slope with slope match capability.
- The cone can be set to plus or minus 4% cone.
- Building the cone rotor into the Alpha chassis provides a more durable product suited to outdoor grading work.
-
Includes:
- Pro Shot Alpha-c Laser Level
- Pro Shot R9 Laser Receiver Detector
- Rod Clamp
- Laser Carrying Case
- Owner's Manual
- The Pro Shot Alpha-c offers the performance of the standard Alpha, plus a custom precision cone rotor head. This version of the Alpha-c offers ±4% cone angle.
-
Specifications
Laser receiver / detector
Pro Shot R7
Horizontal accuracy
± 10 arc sec (± 1/16" per 100') (± 1.5mm per 30m)
Range with detector (diameter)
2000' (610m) Cone slope capability
± 4%, 1/4% increments (Optional high resolution version available) Leveling technology; range
Servo motor self leveling; ± 5º Height alert Normally active, can be disabled Slope matching; range
Single axis with X-axis self leveled; 8%
Rotation coverage 360º Laser beam type; rotation speed
Visible 670nm; 500rpm Laser classification
CDRH Class 3A, IEC Class 3R
Machine control compatible
Yes, with most modern systems
Battery life
75 hrs with 4 C-cells, 48 hrs with optional Ni-MH rechargeable battery
Operating temperature
-4º F to +140º F (-20º C to +60º C) Water and dust resistant IP56
Warranty 24 month defects coverage
