Topcon RL-SV2S dual slope, Rech. Batt. LS100D digital receiver

Topcon
SKU: 313990778
Features:

The Topcon RL-HV2S Self-leveling Dual Grade Laser Kit w/ LS-80X Receiver and Alkaline Batteries is a self-leveling laser kit that can handle flat work, single grade or dual grade applications. The Topcon LS-80X Receiver Sensor included in this kit is a digital device that works with red beam rotary lasers. It is compatible with Bluetooth Laser Manager app that lets you control the laser with your cell phone.

  • Horizontal, vertical, single, and dual slope applications
  • Long-range operation (800 m)
  • Tough IP66 construction rating
  • Extra-long battery life (up to 120 hours)
  • Laser class 1
Laser Manager Mobile App:

The Laser Manager is a revolutionary mobile app that streamlines laser operation by bringing many of the most common functions directly to your mobile device. This innovative functionality speeds up laser setup and allows you to adjust the laser beam across all axes. The Laser Manager App is available for free on both the Google Play Store and the Apple App Store.

  • Setting up position and slope
  • Setting up rotation speed and different working modes
  • Self inspection mode – will guide you easily through the calibration process
Includes:
  • RL-HV2S Dual Grade Laser (Alkaline Batteries)
  • LS-80X Long Range Laser Receiver Sensor 1046259-01
  • Receiver Rod Clamp Holder 6 (312890112)
  • (4) D-Cell Alkaline Batteries (Dry Battery Kit) "NOT INCLUDED"
  • Rugged Hard Shell Carrying Case
  • 5-Year Warranty Guarantee
Specifications:
  • RL-HV2S Laser Specifications:
    • Accuracy: 1/16-inch @ 100-feet
    • Self-Leveling Range: ± 5 degrees
    • Working Range diameter: 2,600 feet
    • Rotation Speed: 300, 600 RPM
    • Light Source: Visible Red Laser 635NM
    • Laser Class: CDRH(FDA) IIIa IEC Class 3R
    • Dust / Water Rating: IP66
    • Operation Time: Alkaline: 100 hours
    • Operational Temp: -4ºF to 122ºF
    • Size: 7.0 x 7.7 x 8.5 in
    • Maximum Power Output: 2.4mW
    • Tripod Screw Thread: 5/8-11
  • LS-80X Receiver Specifications:
    • Working Range (diameter): 2,500 feet with the RL-SV2S, and RL-HV2S Series Lasers
    • Vertical Detecting Range: 3.5 inch
    • LCD Digital Readout Range: 2.7 inch
    • Horizontal Detecting Range: ±45º
    • Strobe Light Suppression: Yes
    • Units / Measurements: mm / cm / inch / fractional inch
    • Grade Resolution Settings:
      • ±0.02 inch
      • ±0.05 inch
      • ±0.10 inch
      • ±0.20 inch
      • ±0.50 inch
    • LCD Grade Indicators: 9 Channels
    • LED Grade Indicators: Orange, Green, Red (On/Off selectable)
    • Display: LCD on each side
    • Buzzer: Loud / Low / Off selectable
    • Bubble Tube: Yes
    • Warning Icons: HI Alert, Low Battery (for the RL-SV2S, RL-HV2S, and RL-200 Series)
    • Battery: One AA/LR6 dry-cell battery
    • Operation Time: Up to 45 hours with alkaline batteries
    • Battery Level indicator: LCD Icon
    • Auto Shut-off: Approximately 30 minutes
    • Dust/Water Rating: IP67
    • Operating Temperature: -4ºF to 122ºF
    • Dimensions ( L x W x H ):
      • Weight
    • Magnetic Mount: Two Round Magnets on Top
    • Receiver Sensor Bracket: Screw mount
